Loose Sheet (No Folding) – Artwork Specification

Loose Sheet – Hole Punching, Perforation & Creasing

LOOSE SHEET

• Artwork Dimension (Refer Diagram)
• Bleeding : 2mm -Margin (Safe Zone) : 5mm



FILE FORMAT

-Final artwork file format : Adobe Acrobat Document (*.pdf) -File Resolution : 300dpi -Color Mode : Process CMYK mode

FONTS

-You must convert to curve, or create outline, or convert to path (depending on your illustration software) all fonts before you convert or export your raw file to PDF file format. -Minimum font size : 5pts

LINE WEIGHT

-Line Weight : ≥ 0.25pts for all lines. -Color Mode : Process CMYK mode

MARKING & TRAPPING

-Never apply any crop mark or trapping onto the files.

LOOSE SHEET WITH HOLE PUNCHING

-Gap for hole punching : 8mm from the edges -Hole punching position : Center of the edges (either Top / Bottom / Left / Right)

SUBMIT ARTWORK FOR LOOSE SHEET WITH HOLE PUNCHING

Example :

For Page 1, hole punching must used Pantone 355C (Green) to indicate. Please indicate clearly the actual position for hole punching at Page 1.

LOOSE SHEET WITH PERFORATION

-Minimum Panel Distance : 45mm -Perforation Line : 1 – 6 Cross Perforation is NOT allowed, for example :

LOOSE SHEET WITH CREASING

-Minimum Panel Distance : 4mm -Creasing Line : 1 – 6 *Please make sure to download our template Product Size Templates to check artwork match with fold/crease line.
